Curs valabi până la modificarea structurii de Cursuri Cisco: 24.02.2020

Cisco DCUCTS – Data Center Unified Computing System C-Series Troubleshooting

In this course you will learn how to install, troubleshoot and configure UCS C-Series servers operating in standalone mode.

You will also learn about different troubleshooting scenarios as well as recommended solutions with regards to level 1 and level 2 integration problems.

Cui i se adresează?

This course is aimed at anyone whose responsibilities include solving level 1 and leve 2 UCS C-Series Standalone Server issues.

Ce veți învăța?

Upon completion you will know how to:

  • Review the UCS C-Series product platform with an emphasis on feature support
  • Describe the initial setup, configuration, and connectivity to ensure proper Cisco Integrated Management Controller (CIMC) operation
  • Review the UCS C-Series troubleshooting methodology as well as present common configuration challenges
  • Describe CIMC utilities that enable performance validation and facilitate data gathering activities for troubleshooting purposes
  • Describe the process to download firmware updates by using Host Upgrade Utility (HUU)
  • Perform server BIOS updates with various methods
  • Describe the correct process to update the server BIOS by using the EFI shell
  • Describe the correct process for recovering a UCS C-Series server by using a USB Recovery Module
  • Describe the features and benefits of the UCS C-Series P81E Virtual Interface Card (VIC)
  • Perform the proper network (LAN) configuration steps for the P81E VIC
  • Describe common troubleshooting issues and recommended solutions for the UCS C-Series P81E VIC
  • Review the Cisco VIC P81E SAN configuration and vHBA properties
  • Describe the Fibre Channel over Ethernet Initialization Protocol (FIP) and validate its proper configuration
  • Describe the process for determining P81E configuration-related problems
  • Review and introduce the RAID controller options for the UCS C-Series servers
  • Introduce the SAS Extender and Expander options for the C-Series servers
  • Configure the LSI 1068E, LSI 9261-8i, and the software ICH10R RAID controllers
  • Identify the symptoms and recommended solutions of RAID adapter and disk failure modes
  • Describe the steps for installing an operating system onto a local disk
  • Describe the steps for installing an operating system by using a SAN boot
  • Describe the process to download and install additional device drivers after successful OS installation
  • Describe common device driver and operating system troubleshooting issues and their recommended solutions
  • Execute the password recovery process for UCS C-Series server CIMC and BIOS passwords
  • Configure management access to the UCS C-Series server through the LAN on Motherboard and NIC ports
  • Configure the UCS C-Series Intelligent Peripheral Management Interface for management access
  • Configure the UCS C-Series Serial over LAN service
  • Describe the rationale and various components that are required to complete UCS C-Series integration with UCS Manager
  • Configure the Fabric Interconnect and Fabric Extender for a UCS C-Series server
  • Configure the UCS C-Series server to operate as part of a UCS Manager instance
Cerințe preliminare:

Students need to have:
DCUCI – Cisco Data Center Unified Computing Implementation

Agenda cursului:

Materialele de curs sunt în limba Engleză. Predarea se face în limba Română.

Citește agenda cursului
Citește agenda cursului
Cisco DCUCTS – Data Center Unified Computing System C-Series Troubleshooting v1.0

UCS C-Series Product Review
C-Series Initial Setup and Configuration
C-Series Troubleshooting Methodology
C-Series Data Gathering Activities

Configuring Firmware Updates

Download Firmware Updates by Using the Host Upgrade Utility
Perform a Remote Update to the Server BIOS
Perform a BIOS Update by Using the EFI Shell
Configure USB Recovery Modules for Server BIOS Recovery

Troubleshooting LAN Connectivity

UCS C-Series P81E Virtual Interface Card Overview
UCS C-Series P81E Virtual Interface Card Configuration
Troubleshoot the UCS C-Series VIC (P81E) Installation and Configuration

Troubleshooting SAN Connectivity

Cisco VIC P81E SAN Configuration
Fibre Channel over Ethernet Initialization Protocol
Cisco VIC P81E SAN Troubleshooting

Troubleshooting Local Disk and RAID

UCS C-Series RAID Controller Overview
UCS C-Series LSI Controller SAS Expanders and Extenders
UCS C-Series RAID Controller Configuration
Troubleshoot RAID Adapter and Disk Failures

Troubleshooting Operating System Driver Issues

Installing a Windows Operating System onto a Local Drive
Installing the Operating System Using a SAN Boot
OS Device Drivers After Installation
Troubleshoot OS Device Driver Problems

Troubleshooting Management Access

Execute CIMC and BIOS Password Recovery
Troubleshoot the LOM and Cisco Card Mode
Troubleshoot IPMI Access
Troubleshoot SoL Access

Configuring UCS C-Series Integration with UCS Manager

UCS C-Series and UCS Manager Integration Overview
UCS C-Series and UCS Manager Installation
UCS C-Series and UCS Manager Troubleshooting

Este recomandat să continui cu:

Nu există cursuri recomandate după finalizarea acestui curs.

Programe de certificare

Nu sunt programe de ceritifcare pentru acest curs.

Detalii curs

Durată
5
zile

Preț
1000
EUR

Modalități de livrare
Predare în clasă, Clasă hibridă, Clasă virtuală
Nivel de specializare
5. Specialized
